PanelPilotACE Design Studio
Build custom interfaces with zero coding.
Design Studio is the free, drag-and-drop software platform for building custom user interfaces on PanelPilotACE displays. Whether you’re developing smart control panels or data logging solutions, this tool allows for fast, flexible design; all without needing to write complex code.
Download PanelPilotACE Design Studio: Version 4.0.2.4064
What Is PanelPilot Design Studio?
Latest Features and Capabilities
PanelPilotACE Design Studio (version 4.0.2.4064) offers a streamlined way to create and manage touchscreen display interfaces for the SGD 43-A and SGD 70-A devices. This full-featured software supports both 4.3” and 7” displays, providing a powerful and visual environment to design applications using simple drag-and-drop tools.
Built for flexibility and speed, the latest release includes support for the CAN bus J1939 protocol (for use with the S70-CAN add-on board), a new number spinner element for intuitive number input and enhanced multi-channel graphing and data logging capabilities. Previous updates have introduced key features like PID control, Ethernet FTP access and support for MODBUS and RS485 communications; making it an ideal toolkit for industrial and embedded interface development.
All PanelPilotACE products are supported by Design Studio, allowing teams to prototype and deploy applications in a matter of days rather than weeks.
Design Studio Learning Hub
Datasheets
Step-by-Step Tutorials
Whether you’re just starting out or building advanced interfaces, the PanelPilot YouTube Channel has tutorials for every level. Get help with setup, navigation, logic tools and display customisation.
PanelPilotACE User Guides
Just starting out or already building with PanelPilotACE? Download the User Guides for clear, step-by-step support on getting the most from Design Studio.
Help When You Need It
Need more support? Visit our Support Centre for helpful resources including FAQs or get in touch with our team; we’re here to help you get the most out of PanelPilotACE.
